Privacy Beam

Wall Systems

Privacy Beams for Open Joint Designs

Longboard Privacy Beams can be used as stand-alone screening members and can be mechanically fastened to any building structure. Alternatively the beams can also be used within the Longboard Privacy Screen System which is available in a floating or an end-frame configuration. Privacy Beam profiles are available in 1″x 5″ or 1″x 3″ dimensions with thickenings in the side wall to allow for mechanical fastening and come in a wide variety of wood grain, solid color, and specialty finish options. The beams are designed to accept matching Longboard end caps where needed to create a premium finished look.

The Longboard Privacy Screen System can be used as an open joint cladding rainscreen when installed in a floating configuration. The system uses single posts that are designed to be installed behind the beams anchoring the system to the sub- structure providing a continuous and seamless look. Spacing for the floating system is created with mounting brackets and spacer bars.

Finishes

(Ready to ship within 1 week for orders less than 15k sq.ft)

Woodgrains

Longboard's woodgrain finishes have a slight texture with a matte sheen.

Solid & Specialty

Textured Matte
Solid

Smooth Satin
Metallic

Textured Matte
Solid

Smooth Satin
Solid

Textured Matte
Solid

Smooth Satin
Solid

Smooth Satin
Metallic

Smooth Satin
Solid

Additional Finishes

(Contact a Sales Rep for Lead Times)

Woodgrains

Longboard's woodgrain finishes have a slight texture with a matte sheen.

Solid & Specialty

Smooth Satin
Solid

Smooth Satin
Metallic

Speckle

Textured Matte
Speckle

Naturally Aged Metals

Textured Matte
Naturally Aged Metals

Smooth Glossy
Naturally Aged Metals

Textured Matte
Naturally Aged Metals

Your screen, and our pictures do not accurately reflect aspects of our finishes – textures, sheen, woodgrain hues, etc. Always order a physical sample before purchase!

Longboard Finish Classification

Type: Woodgrain / Solid / Metallic /
Speckle / Naturally Aged Metal
Surface: Smooth / Textured
Sheen: Matte / Satin / Glossy
Performance: AAMA 2604 / AAMA 2605
Finish Warranty: 15 Year / 20 Year

Longboard® is Innovative Sustainable Quality Visually Stunning

Ease of Install

Our thorough and detailed installation guides offer simple to follow steps to increase efficiency and reduce time on the job site.

The sample images below are illustrative of some of the steps outlined in our documentation.

Acoustics

Like all fin wall systems, our Link & Lock battens allows for the use of acoustic batts for improved sound performance.

Explore the possibilities with the freedom to create a visually stunning space with a product that also serves a practical purpose.

Technical Specifications

Code Compliance

ICC ESR 4183
LADBS – Los Angeles Department of Building and Safety

Combustibility

ASTM E136 – Behavior of Materials in a Vertical Tube Furnace
CAN/ULC S114 (CANADA) – Non-Combustibility (weight loss)
EN 13501 (UK/EU) – Combustibility Classification
EN ISO 1716 (UK/EU) – Heat of combustion (calorific loss)

Flame Spread & Smoke Development

ASTM E84 – Flame Spread & Smoke Development
ASTM E2768 – Flame Spread & Smoke Development
UL 723 (USA) – Flame Spread & Smoke Development
CAN/ULC S102 (CANADA) – Flame Spread & Smoke Development

Light Reflectance

ASTM E1477 – LRV (light reflectance value)

Environmental

LEED – Evaluates a building’s environmental performance
EPD – Life-cycle environmental impact of products

All Longboard systems are available using our Longboard ECO™ line of sustainable aluminum materials. Longboard ECO™ products are made from minimum 50% recycled aluminum and possess verified life cycle impact assessment (LCIA) and product-specific environmental product declarations (EPD).

Product Components

Beams

Dimensions	Product	24’	End Caps (20/box)
1x3”	Privacy Beam	1X3B.289	1BEC.3
1x5”	Privacy Beam	1X5B.289	1BEC.5
2x2”	Single Post	2X2SP.289	2X2PC.2
2x3”	Double Post	2X3DP.289	2X3PC.3

Mounting Accessories

Product	Qty	SKU
1x3” & 1x5” Spacer Block	100, box	2X2SB.N100
1x3” & 1x5” Spacer Bar	1	1X2FB.145
1x3” Spacer Bar	100, box	1X2FB.1
1x5” Spacer Bar	100, box	1X2FB.3
3” Mounting Bracket	100, box	3PSMB.1
#10 Screws	100, box	PECS.N100
