Endura Linear Direct Mount Ceiling
Made of 100% extruded architectural aluminum, the Longboard Endura tongue & groove plank system is built to provide a simply stunning solution for linear ceilings. Various plank designs are available to choose from and are also offered with optional perforation and Soundtex scrim for acoustical performance applications. Easy to install, non-combustible, VOC free, and corrosion resistant, this system complements any interior building design.
Longboard® Endura planks are mechanically fastened to conventionally framed ceiling structures as well as approved suspended ceiling structures and are therefore suitable to be used in all seismic categories. Suspension elements can vary from heavy-duty 15/16” T-grid to struts. Manufactured in either 12 foot or 24 foot lengths they are easily fabricated whether in a pre-fab facility or in the field to suit your project’s conditions.
Why choose Endura planks instead of other linear ceiling products?
Product Description
High-grade extruded aluminum planks, various finishes, dimensions, and a broad range of component trims to choose from.
Fire Safety
Longboard plank systems are inherently Class A fire safe because they are manufactured from 100% non-combustible materials.
Durability
We offer the highest-grade architectural powder coating finishes that comply with exterior grade AAMA 2604 performance standards. Our product does not oil can and will demonstrate unrivalled flatness and rigidity when installed according to instructions.
Sustainability
All Longboard products have life cycle information and EPDs showing environmentally, economically, and socially responsible impacts. Our interior products can contribute various LEED credits and are available in categories that contain recycled content.
Maintenance
Easy to maintain and cost-effective field repairs. Dirt and debris can be easily rinsed, wiped, or washed off with a mild detergent.
Healthy Materials
Longboard products are VOC and Living Building Challenge (LBC), Red List Free and do not adversely affecting indoor air quality and human health.
Acoustic Solutions
Noise reduction is possible using perforated planks in conjunction with the appropriate acoustical materials to create effective acoustical treatment solutions. Perforated planks available also with an optional Soundtex® scrim applied.
Light Reflectance
A variety of product finishes with associated light reflectance values (LRV) are offered that can contribute to occupants’ productivity, comfort, and well-being by providing high-quality lighting.
High Impact Design
Various stock and custom finishes are available to choose from. Longboard’s natural woodgrain finishes contribute to achieving biophilic architectural design, and promote various aspects of WELL Building Standard requirements.
Ease of Installation
Installers can quickly learn tongue and groove installation techniques. Planks are mechanically fastened to conventionally framed ceiling structures as well as approved suspended ceiling structures. Suspension elements can vary from heavy-duty 15/16” T-grid to struts.
Finishes
Most Popular Finishes
(Ready to ship within 1 week for orders less than 15k sq.ft)
Woodgrains
Longboard's woodgrain finishes have a slight texture with a matte sheen.
Dark Bamboo
DBB
Light Bamboo
LBB
Dark Fir
DFR
Light Cherry
LCY
Light Fir
LFR
Blonde Oak
BOK
Beechwood
BEE
Birchwood
BWD
Solid & Specialty
Onyx Black
OBL
Textured Matte
Solid
Shale
SHA
Textured Matte
Solid
Textured Matte
Solid
Smooth Satin
Solid
Dark Brown
DBR
Smooth Satin
Solid
Slate Grey
SGR
Smooth Satin
Solid
Venus
VEN
Smooth Satin
Metallic
Anodic Ice
AIC
Smooth Satin
Metallic
Ultra White
UWH
Smooth Satin
Solid
Bone White
BWH
Smooth Satin
Solid
Black
BLA
Smooth Satin
Solid
Graphite
GRA
Smooth Satin
Solid
Charcoal
CHA
Smooth Satin
Solid
Moonstone
MOO
Smooth Satin
Metallic
Chili Pepper
CHP
Smooth Satin
Solid
Additional Finishes
(Contact a Sales Rep for Lead Times)
Woodgrains
Longboard's woodgrain finishes have a slight texture with a matte sheen.
Black Oak
BKO
Dark Olive
DOL
Light Olive
LOL
Rock Elm
REM
Light Oak
LOK
Grey Hemlock
GHL
Driftwood
DWO
White Oak
WOK
Solid & Specialty
Speckle
Brownstone
BST
Textured Matte
Speckle
Baked Clay
BCL
Textured Matte
Speckle
Burnt Sienna
BSN
Textured Matte
Speckle
Biscotti
BIS
Textured Matte
Speckle
Relicstone
RST
Textured Matte
Speckle
Limestone
LST
Textured Matte
Speckle
Bedrock
BRK
Textured Matte
Speckle
Pebble
PEB
Textured Matte
Speckle
Alabaster
ALB
Textured Matte
Speckle
Textured Matte
Speckle
Naturally Aged Metals
Liberty
LIB
Textured Matte
Naturally Aged Metals
Empire
EMP
Textured Matte
Naturally Aged Metals
Brooklyn
BRO
Smooth Glossy
Naturally Aged Metals
Eiffel
EIF
Textured Matte
Naturally Aged Metals
Golden Gate
GGA
Textured Matte
Naturally Aged Metals
Your screen, and our pictures do not accurately reflect aspects of our finishes – textures, sheen, woodgrain hues, etc. Always order a physical sample before purchase!
Contact us to confirm lead times for orders greater than 15k sq.ft in the Most Popular Finishes category.
Longboard Finish Classification
Type: Woodgrain / Solid / Metallic /
Speckle / Naturally Aged Metal
Surface: Smooth / Textured
Sheen: Matte / Satin / Glossy
Performance: AAMA 2604 / AAMA 2605
Finish Warranty: 15 Year / 20 Year
Longboard® is Innovative Sustainable Quality Visually Stunning
Ease of Install
Our thorough and detailed installation guides offer simple to follow steps to increase efficiency and reduce time on the job site.
The sample images below are illustrative of some of the steps outlined in our documentation.
Perforation & Acoustics
We offer perforation options to offer designers freedom in achieving their desired look while also delivering acoustically enhancing capabilities.
These products meet the same quality and environmental benchmarks of our other products, including being VOC free, LBC red list free, 100% recyclable, and offering up to LR.73 light reflectance.
Through independent testing we have been able to achieve NRC ratings of between 0.7 and 0.8 that verifies our new perforated ceiling systems will reduce reverberation and achieve sound absorption needs.
Explore the possibilities with the freedom to create a visually stunning space with a product that also serves a practical purpose.
Technical Specifications
Code Compliance
- ICC ESR 4182
- LADBS – Los Angeles Department of Building and Safety
Light Reflectance
- ASTM E1477 – LRV (light reflectance value)
Combustibility
- ASTM E136 – Behavior of Materials in a Vertical Tube Furnace
- CAN/ULC S114 (CANADA) – Non-Combustibility (weight loss)
- EN 13501 (UK/EU) – Combustibility Classification
- EN ISO 1716 (UK/EU) – Heat of combustion (calorific loss)
Flame Spread & Smoke Development
- ASTM E84 – Flame Spread & Smoke Development
- ASTM E2768 – Flame Spread & Smoke Development
- UL 723 (USA) – Flame Spread & Smoke Development
- CAN/ULC S102 (CANADA) – Flame Spread & Smoke Development
- EN 13823 (UK/EU) – SBI (single burning item) wall assembly test (cladding, air gap & sheathing)
Structural
ASTM E8 – Tensile Strength Properties
Environmental
- LEED – Evaluates a building’s environmental performance
- EPD – Life-cycle environmental impact of products
All Longboard systems are available using our Longboard ECO™ line of sustainable aluminum materials. Longboard ECO™ products are made from minimum 50% recycled aluminum and possess verified life cycle impact assessment (LCIA) and product-specific environmental product declarations (EPD).
Product Components
V-Groove Planks
| Dimensions | 12’ * | 24’ ‡ | 12’ Perf * | 24’ Perf ‡ |
|---|---|---|---|---|
| 2½” | 3V.145 | 3VP.145 | ||
| 4” | 4V.145 | 4V.289 | - | - |
| 6” | 6V.145 | 6V.289 | 6VP.145 | 6VP.289 |
Smooth Planks
| Dimensions | 12’ * | 24’ ‡ | 12’ Perf * | 24’ Perf ‡ |
|---|---|---|---|---|
| 6” | 6PSP.145 | 6PSP.289 | 6PSPP.145 | 6PSPP.289 |
Channel Planks
| Dimensions | 12’ * | 24’ ‡ |
|---|---|---|
| 6” | 6CH.145 | 6CH.289 |
Acoustical Soundtex® Scrim
| Dimensions | 12’ * | 24’ ‡ |
|---|---|---|
| 6” V-Groove Plank | 6VPA.145 | 6VPA.289 |
| 6” Smooth Plank | 6PSPPA.145 | 6PSPPA.289 |
Accessories
| Product | Qty | SKU |
|---|---|---|
| Quick Screen Clips | 1750, box | CLIP.N1750 |
| Quick Screen Clips | 100, bag | CLIP.N100 |
| Touch Up Pens (Reach out to confirm color with account manager) | - | TUP |
Component Trims
| Type | Style | Product | Dimension | SKU |
|---|---|---|---|---|
| Starter | Precision | Starter J-Track | (5/8”) - 12’ | 1SJT.145 |
| Starter | Traditional | Starter Strip | (1-7/8”) - 12’ | 2SS.145 |
| J-Track | Precision | Two Piece J-Track | (5/8”) - 12’ | 1X1JT.145 |
| J-Track | Precision | J-Track | (5/8”) - 12’ | 1JT.145 |
| J-Track | Craftsman | J-Track | (7/8”) - 12’ | 1JT23.145 |
| J-Track | Traditional | Two Piece J-Track | (1-3/8”) - 12’ | 1X2JT.145 |
| J-Track | Craftsman | Two Piece J-Track | (7/8”) - 12’ | JT23S.145 |
| Corner | Precision | Outside Corner | (3/16”) - 12’ | 05OC.145 |
| Corner | Traditional | Corner Set | (2”) - 12’ | 2CORS.145 |
| Corner | Craftsman | Inside Corner | (3/4”) - 12’ | 1IC.145 |
| Corner | Craftsman | Outside Corner | (1”) - 12’ | 1OC.145 |
| Corner | Traditional | 3" Smooth | (3") - 24 | 3SCP.289 |
| Corner | Traditional | 3" V-Groove | (3") - 24 | 3SVP.289 |
| Type | Style | Product | Dimension | SKU |
|---|---|---|---|---|
| Reveal | Precision | Flat Reveal | (1/2”) - 12’ | 1FR.145 |
| Reveal | Precision | T&G Flat Reveal | (1/2”) - 24’ | 1TGFR.289 |
| Reveal | Traditional | U-Reveal Set | (1-1/2”) - 12’ | 2URS.145 |
| Reveal | Traditional | Flat Reveal Set | (1-1/2”) - 12’ | 2FRS.145 |
| Reveal | Traditional | T&G U-Reveal | (1 1/2”) - 24’ | 2TGURK.289 |
| Reveal | Craftsman | U-Reveal Set | (3/4”) - 12’ | 1URS.145 |
| Reveal | Craftsman | T&G U-Reveal | (3/4) - 24’ | 1TGURK.289 |
| Termination | Precision | Termination Set | (5/8”) - 12’ | 1TS.145 |
| Termination | Traditional | Termination Set | (1-3/8”) - 12’ | 2TS.145 |
| Termination | Craftsman | Termination Set | (7/8”) - 12’ | TS.145 |
| Compression Joints | Traditional | Compression Joint | (1-3/8”) - 24’ | 2CJ.289 |
